The Fiber laser source has super long lifespan of over 100,000 hours withoutany maintenance. No need to spare any extra consumer parts at all . Suppose you will work for 8 hours per day, 5 days a week, the fiber laser could work properly for you for more than 8-10 years without extra costs except electricity.
Ezcad genuine products, user-friendly interface, functional diversity, high stability, high precision. Each board has its own number to ensure that it can be inquired in the original factory. Refuse to fake .
When two red light coincides best focus. Double red light pointer help customers make focus quickly and easily.
We us famous brand to provides precision laser. Standard 110x110mm marking area. Optional 150x150mm, 200x200mm, 300x300mm etc.
It can control the laser on and off. Make the operate more convenicent.
Can protect eyes from laser wave 1064nm, let the operate more safe.(optional)
Fiber laser marking machine can work with most metal marking applictions, such as Gold, Silver, Stainless Steel, Brass, Aluminium, Steel, Iron etc. And it can also mark on many non-metal materials, such as ABS, Nylon, PES, PVC, Makrolon.
| Model | FST-split fiber marking machine |
| Laser Type | Fiber Laser |
| Working area | 110*110/150*150/200*200/300*300(mm) |
| Laser power | 20W/30W/50W/100W |
| Laser wavelength | 1060nm |
| Beam quality | m²<1.5 |
| Application | metal and nonmetal |
| Communication Interface | USB |
| Working voltage | 220V / 50HZ / single phase or 110V / 60HZ / single phase |
| Cooling Mode | Air Cooling |
| Supported graphic formats | AI，BMP，DST，DWG，DXF，DXP，LAS，PLT |
| Controlling software | EZCAD |
| Working temperature | 15°C-45°C |
| Optional parts | Rotary Device, Lift platform, other customized Automation |
